Sanitary Tri Clamp Sample Valve is made of 304/316 stainless steel with a polished surface, meeting hygiene standards. It is economical, affordable, and easy to operate.
It is primarily used for extracting samples from tanks or pipelines. It can also be installed at the bottom of tanks or pipelines for draining residues. Suitable for the food, chemical, pharmaceutical, cosmetic, and biotechnology industries, as well as all other industries requiring sanitary equipment.
| Size | 1/2″-2″. |
| Body&Disc Material | AISI 304 or 316L, (EN1.4301/EN1.4404). |
| Temperature | 14°F to 248°F (-10°C to 120°C), Max 220 ℃ (PTFE) |
| Max pressure | 145psi (10bar) |
| Seal | EPDM, Silicone, PTFE |
Operating principle：when turn the hand wheel clockwise, the valve shaft and seal rise up. At this time, valve is open for sampling. When turn the,hand wheel anti-clockwise, the valve shaft and seal go down,at that time, the valve is closed.
